Description
One-way and Talkback, 3 Zone, Page Control plus all call; separate outputs for each paging mode. Dipswitch programmable features include built-in tone generator for night ring, time clock, door bell and background music input which automatically mutes in zones being paged. Battery backup compatible (VPB-260) and expandable to virtually an unlimited number of speakers when used with additional power supplies.
- Provides 3 Zones Of 1 Way And/Or Talkback Paging
- Interfaces With Telephone System Via A Loop Start/Ground Start C.O. Line Position
- Page Override Input
- Supports Two Talkback Speakers Per Talkback Zone
- Programmable Features Per Zone: Background Music, Tones, Talkback
- Built-In All Call
- Transmit And Receive Volume Controls
- May Be Accessed From A Dedicated Single Line Telephone Set)
- Standard 66 Blocks Used For Connections
- Background Music Input With Volume Control
- Dial Tone
- Accepts Pulse Or DTMF Dialing
- Integral Battery Backup Input
- Standard AC Receptacle Powered
- Built-In Power
- Built-In Tone Generator (Single/Warble) With Volume Control
- Dual Line Voltage Ready
- UL/CSA/CE
Dimensions: 7.1″ H x 10.0″ W x 3.0″ D (18.0 cm x 25.4 cm x 7.62 cm)
Weight: 6.25 lbs (2.84 kg)
